Fan Spray Nozzles

Designed for effective impact and even spray distribution. Ideal for conveyor belts when washing, coating, or wetting is required. Fanspray nozzlesare either axial or deflector style.

Configure Your Exact Fan Spray Nozzles

Start Here

BETE EZ Quick Connect - Maintenance Made Easy

Learn how you can change nozzles in seconds without using any tools.BETE EZ Quick Connectis a three-piece nozzle design with a base, gasket, and interchangeable nozzle tip. Automatic nozzle alignment takes place upon insertion for easy installation.

Customers rely on BETE for the latest innovations in spray technology. The EZ Quick Connect thread adapter accessory accommodates other standard BETE nozzles.


Improve Your Process with Spray Header Fabrications

Choose your fan nozzle and BETE can custom design and fabricatespray headersfor precise nozzle placement to optimize your spray process.

Fabrication is BETE’s specialty from complex ASME Code compliance to simple flush pipe assemblies.

Contact us
Tell us more about your spray application
Fan Nozzle Products
BETE BJ spray nozzle

BJ LOW FLOW FLAT FAN NOZZLES

可互换的扇形喷嘴Tips With Integral Strainer
BETE BJH spray nozzle

BJH FLAT FAN NOZZLES WITH TUNGSTEN CARBIDE INSERTS

可互换的扇形喷嘴Tips With Integral Strainer
蠢人NF的细节H

NFH FLAT FAN NOZZLES WITH TUNGSTEN CARBIDE INSERTS

High Impact Spray Nozzles for Maximum Life and Wear Resistance
蠢人NF的细节V

NFV HIGH-IMPACT FLAT FAN NOZZLES WITH OPTIONAL INTEGRAL STRAINER

Removable Strainer Designed for Easy Cleaning
蠢人NF的细节

NF FLAT FAN NOZZLES

整块的Construction Fan Spray Nozzles for Coating and Lubricating
蠢人NF的细节D

NFD DOVETAIL FLAT FAN NOZZLES

Low Maintenance Interchangeable Fan Spray Nozzle Tips
蠢人NF的细节S

NFS STUBBY FLAT FAN NOZZLES

Compact Fan Nozzles for Tight Spaces With Low Clearance
Detail of the BETE EZNF

EZNF QUICK CONNECT STRAIGHT JET OR FLAT FAN NOZZLES

Interchangeable Nozzle Tips With Base and Gasket
Detail of the BETE FF

FF DEFLECTED FLAT FAN NOZZLES

UL Approved Nozzles With Extra-Wide Fan Spray Angle For Fire Fire Suppression

SPN HIGH-IMPACT DEFLECTED FLAT FAN NOZZLES

Powerful Narrow Fan Spray With Least Atomization
Detail Fan Spray Pattern Icon

Fan Spray Nozzles

There are two types of fan nozzle designs: axial and deflector. For axial fan nozzles, a thin flat sheet of liquid is produced when the fluid exits the orifice, and the spray begins to widen and gradually moves outward from the nozzle. The spray pattern is formed for deflector fan nozzles as the liquid exits the orifice; it is deflected off an external surface, creating an extra-wide fan spray pattern.


Axial

  • Spray widens as it moves outward
  • Uniform distribution with tapered edges
Detail of Tangential Spray

Deflector

  • The spray is deflected off an external surface
  • Creates an extra-wide fan spray pattern
Examples of Why You Would Choose This Spray Pattern Over Others
  • Fan nozzles are often the most practical choice for conveyor belt applications. Fan nozzles are your best choice whenever something moves and must be washed, wetted, or coated. Examples are conveyor belt cleaning, suppressing coal dust on a conveyor, and coating molds.

  • When a high impact force is necessary for either cleaning or other applications, a fan-style nozzle may give you the most optimal results. The SPN series and narrow-angled NF nozzles will provide a large impact force while generating relatively low flow rates.

Nozzle Spray Videos

Fan Nozzle: BETE NF 4065


Fan Nozzle: BETE NF 4015


Fan Nozzle: BETE NF 20065


Fan Nozzle: BETE NF 40120


Deflected Fan Spray Nozzle: BETE FF 375-145


Deflected Fan Spray Nozzle: BETE SPN 6050
