DESIGN FEATURES
六个耐堵塞的最大含量®在一个集群中排列的全锥喷嘴,以四面八方进行喷雾
Can be supplied with various BETE nozzles for any desired application
Spherical omnidirectional coverage
如何实现喷雾图案
A manifold distributes water to several standard full cone nozzles with orientations positioned to achieve a full omnidirectional spray coverage
Available Spray Angle
360°
Flow Rate Range
7.38 to 124 gpm
Available Connection Types
- Pipe: 3/4, 1
- Connection Methods: Thread (NPT, BSP, Female)
Materials
Brass, 316, A494 CW2M (cast Nickel Alloy C-276)
Flow Rates, Spray Angles, Connections
Tank Cleaning
Select a nozzle number below for performance graph, drawings, and to request a quote.
在差压(PSI/bar)下计算流速(GPM/LPM)。
Nozzle Number
Connection Sizes
喷雾角
流速(GPM) @差分(PSI)(密度:1 SG)
10 psi
20 psi
30 psi
40 psi
50 psi
60 psi
